Lastra di silicio a 6 pollici di IC con TTV<10um

Sono ora online in chat

Lastra di silicio a 6 pollici di IC con TTV<10um

6 Inch IC Silicon Wafer With TTV<10um
6 Inch IC Silicon Wafer With TTV<10um 6 Inch IC Silicon Wafer With TTV<10um 6 Inch IC Silicon Wafer With TTV<10um 6 Inch IC Silicon Wafer With TTV<10um

Grande immagine :  Lastra di silicio a 6 pollici di IC con TTV<10um

Dettagli:
Luogo di origine: La Cina
Marca: ZMSH
Certificazione: ROHS
Model Number: Silicon004
Termini di pagamento e spedizione:
Quantità di ordine minimo: 25 pz
Prezzo: By case
Packaging Details: 25pc cassette box/jar box
Tempi di consegna: in 30days
Termini di pagamento: T/T
Capacità di alimentazione: 2000pc/months
Descrizione di prodotto dettagliata
arco: <10um> Drogante: /N-type P tipo
Difetti: Nessuno Nome di prodotto: Lastra di silicio di IC
Finitura superficia: ssp/dsp orientamento: (100), (110), (111)
filo di ordito: <20um> Dimensione: 1inch, 2inch, 3inch, 4inch, 6inch, 8inch, 12inch
Evidenziare:

Lastra di silicio di superficie di SSP IC

,

Lastra di silicio a 6 pollici di IC

,

Wafer a semiconduttore di IC

Product Description:

IC Silicon Wafer is a kind of high-quality semiconductor wafer used in integrated circuit (IC) production. It features high quality and reliable performance, making it the ideal choice for IC production. The IC Silicon Wafer is available in different sizes, including 1inch, 2inch, 3inch, 4inch, 6inch, 8inch and 12inch. It also features different resistivity levels, ranging from 1 to 10 ohm, and dopants of P-type or N-type. The IC Silicon Wafer also offers excellent flatness of less than 50um and warp of less than 20um. What's more, the IC Silicon Wafer is specially designed for SOI silicon wafers, making it perfect for 4inch, 6inch and 8inch SOI wafers. For high-end IC production, the 6inch silicon wafer is the ideal choice.



Features:

  • Product Name: IC Silicon Wafer
  • Orientation: (100), (110), (111)
  • Thickness: 0.28, 0.35, 0.5, 0.525, 0.625, 0.7, 0.725
  • Dopant: P-type, N-type
  • TTV: <10um
  • Size: 1inch, 2inch, 3inch, 4inch, 6inch, 8inch, 12inch
  • PECVD SIO2 Wafers
  • 8inch Silicon Wafers
  • Si3Nx Coating Wafer


Technical Parameters:

Property Value
Defects None
Orientation (100),(110),(111)
Size 1inch, 2inch ,3inch ,4inch, 6inch ,8inch ,12inch
Test Yes
Particle <30/cm2
Thickness 0.28/ 0.35/ 0.5/ 0.525/ 0.625/ 0.7/ 0.725
Warp <20um
Dopant P-type /N-type
Flatness <50um
Surface Finish SSP/DSP
Si3Nx Coating Wafer Yes
LPCVD Yes
PECVD SIO2 Wafers Yes


Applications:

IC Silicon Wafers, with Brand Name ZMSH and Model Number Silicon004, are produced in China and certified by ROHS. The minimum order quantity is 25PC, and the price is set on a case-by-case basis. The packaging details are 25pc cassette box/jar box. The delivery time is within 30days and the payment terms are T/T. The supply ability is 2000pc/months. The Dopant is P-type or N-type, and the Flatness is <50um. The Thickness is 0.28/ 0.35/ 0.5/ 0.525/ 0.625/ 0.7/ 0.725. Particles are <30/cm2. These IC Silicon Wafers are especially suitable for SOI silicon wafer applications, such as 4inch 6inch 8inch SOI wafers and 6inch silicon wafers.



Customization:

Customized IC Silicon Wafer

Product Name: IC Silicon Wafer
Brand Name: ZMSH
Model Number: Silicon004
Place of Origin: CHINA
Certification: ROHS
Minimum Order Quantity: 25PC
Price: By case
Packaging Details: 25pc cassette box/jar box
Delivery Time: in 30days
Payment Terms: T/T
Supply Ability: 2000pc/months
Surface Finish: SSP/DSP
Test: Yes
Defects: None
Particle: <30/cm2
Features: PECVD SIO2 wafers, SiO2 coating substrate, SOI silicon wafer.



FAQ:

Q: What is the brand name of the IC Silicon Wafer?
A: The brand name of the IC Silicon Wafer is ZMSH.
Q: What is the model number of the IC Silicon Wafer?
A: The model number of the IC Silicon Wafer is Silicon004.
Q: Where is the IC Silicon Wafer made?
A: The IC Silicon Wafer is made in China.
Q: Is the IC Silicon Wafer ROHS certified?
A: Yes, the IC Silicon Wafer is ROHS certified.
Q: How many IC Silicon Wafers can be purchased in one order?
A: The minimum order quantity is 25PC.
